COMMENCAL META HT 20 DIRT

The META HT Kids range features real enduro mountain bikes designed for young people. They love adventuring off the beaten track and may also be particularly comfortable on a pump track or on the streets.

The range consists of three models with different wheel sizes; 20-inch, 24-inch and 27.5-inch (JR).

But forget wheel size for a minute, because all of the META HT Kids range showcase high-end frames. The series of tubes are specifically designed to offer comfort and liveliness. The rear triangle tubes are worked to generate a vertical flex and therefore ensure comfort. All three models are equipped with a telescopic fork which reduces friction as much as possible so that the travel is used to the full, even during small impacts and for smaller, lighter humans. The comfort and grip are exceptional for a bike of this size.What a way to spend their days on a bike!

About the META HT 20”

On the META HT 20, the frame is semi-rigid with a 100mm telescopic fork. This fork was specifically developed by our engineers in collaboration with MANITOU. The main objective is to reduce friction as much as possible so that the travel is used to the full, even during small impacts and for smaller, lighter humans. The comfort and grip are exceptional for a bike of this size.

1. Specs

   • CADRE2021 Meta HT 20

     Alloy 6061, triple butted tubes, T4, T6.

   • AMORTISSEUR–

   • FOURCHEMANITOU Machete Junit Pro, 100 mm travel

     20, kids specific air cartridge, rebound, compression. Custom tuned for Commencal Bicycles. Boost (15 x 110 mm)

   • JEU DE DIRECTIONACROS ZS44 / ZS56

     Alloy cups, sealed bearings

   • POTENCERIDE ALPHA Freeride 40 mm

     40 mm extension, 31,8 mm

   • CINTREPROTAPER Junit Rizer bar

     31,8 mm, 600 mm width, 25 mm rise, Alloy 7050-T76, Stealth

   • GRIPSPROTAPER Junit 27 mm

     Kids specific 27 mm diameter

   • FREINSTEKTRO HD-J285, Hydraulic disc brake

     Rotors: TEKTRO 180 / 160 mm, 6-bolt

   • SHIFTERSSRAM GX

     10s

   • GUIDE CHAINE–

   • DERAILLEURSRAM GX

     10s, short cage

   • BOITIER DE PEDALIERAEROZINE BSA 30

     Threaded

   • PEDALIERAEROZINE Xeon-A1, 135 mm crank arms, 30 mm axle, 7075 alloy

     Chainring: AEROZINE Direct Mount 32t, Narrow-Wide, full CNC

   • CHAINEKMC X10

     10s

   • CASSETTESRAM PG-1020

     10s, 11-36t

   • JANTESALEXRIMS MD30

     20, 32h, 30 mm inner width

   • MOYEUXFront: FORMULA RX-26 – Rear: FORMULA DC-711

     Front: 32h, sealed bearings – Rear: 32h, sealed bearings

   • RAYONSSAPIM Leader

     J-Bend 2.0 mm, stainless, with Nylok, black

   • PNEUSRear: MAXXIS MINION DHR II 20 – Front: MAXXIS MINION DHR II 20

     Rear: 20X2.30 WIRE Clincher M327P no tubeless – Front: 20X2.30 WIRE Clincher M327P no tubeless

   • TIGE DE SELLERIDE ALPHA

     31,6 mm, 250 mm length

   • SELLESDG Fly Jr

     Kids specific, reinforced sides

   • POIDS10,6 kg

     Without pedals. Weight may differ slightly due to manufacturing tolerances.

   • PEDALESYes

   • COULEURDirt

     Shiny finish

   • ACCESSOIRESSmall pedals, chainstay protector, seatstay protector

2. Vidéos

3. Tech

   • TYPE DE VELOALL MOUNTAIN HARDTAIL 20

   • CADREAl 6061 T6

   • POIDS DU CADRE–

   • DEBATTEMENT ARRIERE–

   • ENTRE-AXE / COURSE–

   • COMPATIBLE PIGGY BACK–

   • BUSELURES AMORTISSEUR–

   • HAUTEUR DE FOURCHE RECOMMANDEE / MAX400 mm – 420 mm

   • DOUILLE DE DIRECTIONTAPERED 1-1/8 / 1-1/2

   • JEU DE DIRECTIONZS44 / ZS56

   • LARGEUR MAXIMALE PNEUS (ETRTO)63 mm

   • STANDARD FREIN A DISQUEIS 160 mm

   • DIAMETRE MAX DISQUE DE FREIN AR160 mm

   • DIAMETRE TIGE DE SELLE / COLLIER DE SELLE31,6 mm – 34,9 mm

   • BOITIER DE PEDALIERBSA 68 mm

   • ISCGNo

   • DERAILLEUR AVANTNo

   • AXE DE ROUE ARRIERE135 x 9 mm
