COMMENCAL META TR STAFF EDITION

NO BLABLA

Le META TR Staff Edition, avec sa finition “Sunset” directement inspirée du SUPREME DH V5 roulé par Hugo Frixtalon lors de la World Cup de Lourdes 2022, est le mix composants / cadre fétiche de notre staff en Andorre.

160mm de débattement à l’avant, 140mm à l’arrière, roues en 29” : ce modèle Staff Edition permet de s’amuser sur un trail technique à côté de chez soi, se faire un après-midi Bike Park ou s’engager sur une manche d’Enduro World Series. Rien n’a été laissé au hasard :

– Fourche Fox 38 Factory, pour un montage volontairement “bodybuildé”. Avec son traitement Kashima, elle est pour nous la meilleure fourche d’enduro à l’heure actuelle : smooth, précise et facile à régler.

– Amortisseur Fox Float X2 Factory, le modèle que nos teams roulent en DH. Il encaisse de façon excellente les chocs à haute et basse vitesse tout en étant quasi “blocable” à la montée afin de consommer le moins de débattement et d’énergie possible au pédalage.

– Roues Crankbrothers Synthesis Enduro Carbon associées à des moyeux Industry Nine Hydra. Celles roulées par le COMMENCAL Enduro Project, notre team laboratoire, et qui présentent selon nos Product Managers le meilleur rapport performance / espérance de vie, tout en restant confortables.

– Pneus Schwalbe Magic Mary en 29×2.40, carcasse “Super Trail” et gomme ultra soft, LE choix de référence pour un vélo d’enduro.

– Des freins Shimano XTR 4 pistons avec disques de 203mm. La puissance, l’excellence.

– Une transmission Sram XO1 Eagle fiable, précise et silencieuse.

– Un cockpit Renthal : shappe parfait, sobre et classe.

Voici le Dream Bike du staff COMMENCAL en Andorre. Prêt pour toutes les aventures aussi bien que pour la compétition.

1. Specs

   • CADRE2022 META TR, 140 mm travel

     29”, Alloy 6066, triple butted tubes, T4, T6. Enduro bearings on M / L / XL

   • AMORTISSEURFOX Float X2 Factory

     210 x 55 mm, HSC, LSC, HSR, LSR, 2-postion adjustment

   • FOURCHEFOX 38 Factory, 160 mm travel

     29″, Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 44 mm offset, 3 Tokens

   • JEU DE DIRECTIONACROS ZS44 / ZS56

     Alloy cups, sealed bearings

   • POTENCERENTHAL Apex

     40 mm extension, 31.8 mm

   • CINTRERENTHAL Fatbar Lite on S/M – RENTHAL Fatbar on L/XL

     31.8 mm, 760 mm width, 30 mm rise, Alloy 6061 on S/M – 31.8 mm, 800 mm width, 30 mm rise, Alloy 6061 on L/XL

   • GRIPSODI Elite Motion

     Single clamp, black

   • FREINSSHIMANO XTR, 4 pistons, I-Spec EV compatible

     Rotor: SHIMANO SM-RT86 203 mm, 6-bolt, Ice Technology Freeza

   • SHIFTERSSRAM X01 Eagle

     12s, Black

   • DERAILLEURSRAM X01 Eagle

     12s, Black

   • BOITIER DE PEDALIERSRAM DUB

     Pressfit

   • PEDALIERSRAM Descendant Carbon Eagle, 170 mm crank arms, Boost

     Chainring: SRAM Descendant X-Sync, 32t

   • CHAINESRAM XX1 Eagle

     Copper finish, 12s

   • CASSETTESRAM XG-1299

     Copper finish, 12s, 10-52t

   • JANTESCRANKBROTHERS Synthesis Enduro Carbon

     Rear: 29″, 32 holes, 29.5 mm inner width – Front: 29″, 28 holes, 31.5mm inner width

   • MOYEUXINDUSTRY NINE Hydra

     Rear: 32 holes, 0.52° ultra fast engagement, 6 pawls – Front: 28 holes

   • RAYONSSAPIM

     Sapim CX-Ray front / Sapim CX-Sprint rear

   • PNEUSRear: SCHWALBE Magic Mary – Front: SCHWALBE Magic Mary

     Rear: 29″ x 2.4″, Super Trail, Addix Ultra-Soft, Tubeless Ready – Front: 29″ x 2.4″, Super Trail, Addix Ultra-Soft, Tubeless Ready

   • TIGE DE SELLEFOX Transfer Factory

     31.6 mm, travel: 125 mm on S, 150 mm on M, 175 mm on L and 200 mm on XL, 1x lever + seat tube adaptor to 34.9 mm

   • SELLEFIZIK Terra Alpaca X5

     145 mm, Fiber reinforced nylon Wing Flex

   • POIDS15,8 kg

     Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

   • PEDALESNo

   • COULEURSunset

     Shiny

   • ACCESSOIRESDown tube protector, chainstay protector, seatstay protector, fork fender Fox 36 specific

2. Tech

   • TYPE DE VELOTRAIL 29″

   • CADREAL-6066

   • POIDS DU CADRE3,7 kg

   • DEBATTEMENT ARRIERE140 mm

   • ENTRE-AXE / COURSE210 x 55 mm

   • COMPATIBLE PIGGY BACKYes

   • BUSELURES AMORTISSEUR20 x 10 mm

   • HAUTEUR DE FOURCHE RECOMMANDEE / MAX551 mm / 571 mm

   • DOUILLE DE DIRECTIONTAPERED

   • JEU DE DIRECTIONZS44 / ZS56

   • LARGEUR MAXIMALE PNEUS (ETRTO)65 mm

   • STANDARD FREIN A DISQUEPOSTMOUNT 200 mm

   • DIAMETRE MAX DISQUE DE FREIN AR220 mm

   • DIAMETRE TIGE DE SELLE / COLLIER DE SELLE34,9 mm / 38,5 mm

   • BOITIER DE PEDALIERBB92

   • ISCGISCG 05

   • DERAILLEUR AVANTNo

   • AXE DE ROUE ARRIERE12 x 148 mm

3. Géometrie

4. Tailles

5. Photos

6. News
